Nix5150's #1 Frankenstrat build (in progress)

Postby Nix5150 » Fri Sep 09, 2011 10:29 am

Hi all hoplefully through all the threads ive read through i should be able to make at least a decent and almost accurate frankenstrat for my first one ever ive done the vh 1 guitar at least 3 times and ive got that down to a T.

Ok well first off id like to thank chillybeef for his templates.

I will be going for the relic look of a few of eds pics of his vh1 which i will show and then of course i will add a few more that i see in forums most notably steveu1s, pcr and frankenstrat and chillybeef list goes on lol

•here will be my build list

Divebomb monster replica body
Musikraft frankenstrat neck
divebomb pickguard
divebomb neck and possibly switch not sure yet
seymour duncan 78model pickup
evh or gibson low friction pot 500k
switchcraft mono jack
stratocaster jack plate
schaller mini locking tuners left style
screws that ive aged
1971 quarter
oh and obviuously orignal floyd rose with old style arm

For paint and tape
•tape im gonna use 3m fine line variants of 1/4, 1/2 and 3/4 and 1"

Paint i will be using duplicolor black, and white and will be going with super red II also from duplicolor

Unfortuanately due to crappy job this build may take awhile so im going to mainly focus on trying to get the body as accurate i can from everyones builds and talks over broken screws aging etc
mainly because im not to worried on how parts will fit on because that can alwasy be changed later on and as long as it plays good and has good tone thats all im shootin for as for that

so i will be ordering the body hoplefully next thursday and then i can finally start on the paint job

for now here are a few pics of what i have
[/img]

User avatar
Nix5150
Posts: 1626
Joined: Tue Aug 30, 2011 9:14 pm
Location: indiana

RE: Nix5150

Postby Nix5150 » Fri Sep 09, 2011 10:35 am

Pics of tape (not all of it yet)

Pic of 1971 quarter i just got in mail today from ebay

User avatar
Nix5150
Posts: 1626
Joined: Tue Aug 30, 2011 9:14 pm
Location: indiana

RE: Nix5150

Postby Nix5150 » Fri Sep 09, 2011 10:49 am

heres a pic of my attempt at the bumblebee awhile back that ive been practicing relicing on and aging somewhat just thought id show it i have not used a template for the taping either

User avatar
Nix5150
Posts: 1626
Joined: Tue Aug 30, 2011 9:14 pm
Location: indiana

RE: Nix5150

Postby Nix5150 » Fri Sep 09, 2011 11:01 am

Alright the only thing ive actually done for my project so far is aged some screws i won't be using them all though i will be using the pickguard screw up in front

thanx to chillybeef for the info i will show you pics on how to do this bc thats what i wanted when i looked through here and there was no clear pics just pics of them already done and explaining it. theres is no salt water pic but i will take one to make this complete lol

•Here is step by step for how to age screws..
first u need a container of some sort u want to pour bleach into 1/4 full or 1/2 a cup works basically just enough to submerge your screws let sit for 6 hours

after 6 hours also i recommend doing this at around 12 to 3 depending on how late you stay up for instance i did the original ones in my pic from 11 to 5 pm, after the 6 hours wash the screws off and get another container i have these little plastic ones but u can use the same one, just dump the bleach out when done, second now your going to put normal salt water kinda alot of salt in the water and you can warm it up if u want too but you don't have too place your screws back in and wait till the next day when you wake up or whenever your not busy look in your container and your screws should look like this :) enjoy

User avatar
Nix5150
Posts: 1626
Joined: Tue Aug 30, 2011 9:14 pm
Location: indiana

RE: Nix5150

Postby Nix5150 » Fri Sep 09, 2011 11:57 am

ok im gonna show a pic of where i plan on putting holes and sizes and i would like more eyes i think it looks about right what do you guys think any suggestions or opinions ?
the middle hole is to big but does it look in the right position? this stuff irritates me if it doesn't look exact it will haunt me later lol

User avatar
Chillybeef
Posts: 758
Joined: Sat Oct 16, 2010 7:27 pm

RE: Nix5150

Postby Chillybeef » Fri Sep 09, 2011 12:15 pm

Yes, that looks pretty close. the middle one looks kind of big, but it's hard to visualize at this point. I would just work your way up until it looks right to you.

User avatar
Nix5150
Posts: 1626
Joined: Tue Aug 30, 2011 9:14 pm
Location: indiana

RE: Nix5150

Postby Nix5150 » Fri Sep 09, 2011 12:19 pm

ok thanks this is really helpful btw do you age your quarters? i did on a test quarter dif year and it made it really plain and had a green color on out side and i don't think it looks good at all i have an idea on how to without it looking like that but some people don't really look aged am im trying to go for an accurately as possible build here

User avatar
Chillybeef
Posts: 758
Joined: Sat Oct 16, 2010 7:27 pm

RE: Nix5150

Postby Chillybeef » Fri Sep 09, 2011 1:17 pm

I personally don't age my quarters, except I do rub some ashes on them to make them look old. Maybe a touch of black shoe polish to exagerate the shape of the head, and the edges, to suggest it's old and beat up. I also accidently dinged it up with a screwdriver, and it certainly makes it look nice and beat up in direct light

nothing to worry about though, I'm sure eddie's quarter doesn't have any marks worth noting

User avatar
Nix5150
Posts: 1626
Joined: Tue Aug 30, 2011 9:14 pm
Location: indiana

RE: Nix5150

Postby Nix5150 » Fri Sep 09, 2011 1:24 pm

ok thanx man after work i plan on drilling the holes and putting the chip on it and aging i already took a punch and got my holes ready to be drilled exactly where i want them do you have a good picture of one of your quarters? id love to see a decent pic of it and also reference for the chip or dent by the i in liberty

User avatar
Nix5150
Posts: 1626
Joined: Tue Aug 30, 2011 9:14 pm
Location: indiana

RE: Nix5150

Postby Nix5150 » Fri Sep 09, 2011 9:34 pm

Alrighty after lookin through some pics (the seymour duncan pics of the franky and some fellow halens quarters) i got my quarter placement holes and sizes (roughly)***

•heres a pic of where i used a punch to center out my holes the black is where id like them to be but after punching i realized it possibly could have made hold bigger than i wanted and would show in finalization of the quarter so i stuck with them i would have liked to make the left arrow a smidge up and the bottom arrow to the left but i think it turned out nice

•heres a pic of me doing the chip on the I in liberty i used the smallest key file and slowly chizzed it i also took a normal file and used the edge of to form a upside triangle and as a starting for the roundness of the keyfile

•here's result before aging small holes are a 1/8" drill bit and big one in center is a 3/16th


•pic of what i did to age i used some ashes and from taking screws out of the bleach for aging when you place them on a paper towel it left some of the rust color liquidfied so i smeared a bit of that on there as well

•here is the final result let me know what you guys think im very open to suggestions and opinions :D Note* the chip by the I is the same as pic above i know in this pic it makes it looked messed up lol


Radiohead
Posts: 191
Joined: Sat May 01, 2010 9:13 pm
Location: Toronto

RE: Nix5150

Postby Radiohead » Sat Sep 10, 2011 5:30 am

Looks good so far. If you have not ordered your stuff yet, I would stay away from Divebomb altogether. Just do a search on this site and you quickly see why.

The body and neck I got from Musikraft were excellent and they are very professional to deal with.

User avatar
Nix5150
Posts: 1626
Joined: Tue Aug 30, 2011 9:14 pm
Location: indiana

Postby Nix5150 » Sat Sep 10, 2011 7:27 am

RADIOHEAD- yea ive been reading that but then also ive seen people do theres with one and its turned out fine unfortunately due to how i barely make 200$ every 2 weeks im gonna probably go with divebomb and if indeed his body do not work or ( suck** not saying they do yet divebomb) then i will save for a new body and redo it thanx for the opinions tho im definetely going with there necks (mk) tho have you experienced with divebomb ??
thanx im glad someone thinks my quarter looks ok

User avatar
Nix5150
Posts: 1626
Joined: Tue Aug 30, 2011 9:14 pm
Location: indiana

Postby Nix5150 » Wed Sep 14, 2011 9:12 pm

well i am ordering a franky body from kne guitars tomorrow only because i like the pics better more descripted i guess and then eventually in another two weeks i am buying the neck from musikraft unless anyone has a neck for cheaper but same qualities or even companys

User avatar
Nix5150
Posts: 1626
Joined: Tue Aug 30, 2011 9:14 pm
Location: indiana

Postby Nix5150 » Wed Sep 14, 2011 9:21 pm

actually divebomb because the ordering thing on kne guitars is make me P oed so hopefully it doesn't take long to ship :/

User avatar
Chillybeef
Posts: 758
Joined: Sat Oct 16, 2010 7:27 pm

Postby Chillybeef » Wed Sep 14, 2011 9:44 pm

If you haven't yet ordered from DB, I would give mitch a shot...Even though he wasn't able to contact me, to confirm payment, I will be receiving the body tomorrow, less than 2 weeks after paying...Mitch ships FAST...VERY fast...Even though he seems to be having issues, he still made it right for me, just like everyone suggested.
